Gantry machining center HFM-1302
Product NO.:
HFM-1302
Applications:
Buy Online Download album
Share:
  • Product Overview
  • Parameters
  • Features
  • Applications
  • Related Products


>V-type structure machine base, high rigidity rib, scientific span distance design, large bearing surface, to keep the best dynamic horizontal accuracy.

>Propped up by large size column and box-beam structure to insure the best rigidity. Hatchback design beam and widened slide way, machine head's gravity center averagely load on beam's center, to achieve better motion accuracy, superb heavy cutting capability, and unique high stability of the complete structure.

>The best spindle configuration, spindle centerline close to Z-axis sliding rail, which can obviously reduce the heat displacement and bending deformation caused by cutting torque, to insure the best accuracy.

>Suspensory prop-up of Z-axis' double cylinder, close to motion center, symmetrical to the spindle, drive screw and spindle motor hub, to exclude the unbalanced torque, to insure the accuracy of micro feed and long-term manufacture.


Accessories
Standard  Optional
1. Fully enclosed guard  1. Chip remover device
2. Auto lubrication system 2. Coolant through spindle(CTS)
3. Pneumatic tool exchange arrangement 3. Oil-Water separator
4. Blowing device 4. 4th axis rotary table
5. Coollig  arrangement/Lighting arrangement
6. 3 color light
7. Adjusting pad block
8. Spindle coolant arrangement
9. Air conditioner for electric cabinet
10. Tool, Toolbox
11. Technicaldocument
12. Tools Kit


Compared
   Vertical machining center               Gantry machining center
   HFM-1302   HFM-650   HFM-700   HFM-800V   HFM-1100V   HFM-960L   HFM-850L   HFM-1502   HFM-700L   HFM-1160L   HFM-1580   HFM-1890
Parameters
HFM-1302
Travel
Travel X
X axle-2200mm
Travel Y
Y axle-1400mm
Travel Z
Z axle-800mm
Worktable
Table size
1000mm*2000mm
T-slot size
7*22mm
Max load
3000kg
Spindle&3-Axis
Spindle taper
BT50
Spindle speed
6000 rpm
Spindle center to table
120-920mm
Spindle center to column
None
Spindle Motor
18.5/22kw
Three axis motor
40/30/30Nm
Rapid feed rate
10m/min
Cutting feed rate
5000mm/min
Accuracy
Positionging accuracy
0.01mm
Positionging repeatability
0.005/300mm
Other
Air pressure
6kgf/cm2
Input power
35KVA
Tool magzine
24/30
Weight
15000kg
Overall dimension (L*W*H)
7000mm*4000mm*4300mm
● The above specifications are for reference, the company has the right to change at any time, without notice.


Machine Hight Lights
1. Pyramid Structure design and the machine base is widest of the same model, which can provide reliability to ensure the processing accuracy.
2. The weight of machine base is 2.6T, with the best stiffness and stability when high-speed operation.
3. Based on super-strong column design, the rigidity can reach the best performance.
4. Super-strong 4-guideways design on Y-axis and ensure the moving stroke performance with best stability.
5. Y-axis travel is 700mm suitable for moulding.

Optional Controller
MITSUBISHI
SIEMENS
FANUC

High precision, High rigidity spindle
The spindle adopts super precision angular contact ball bearings.
9000~10000rpm spindle as standard accessory for feasible.

3 Axis servo motor & 3 axis guidway
The spindle adopts super precision angular contact ball bearings. 10000rpm spindle as standard accessory.
High speed linear guide ways used on 3-axes of machine, accomplish super load capacity and rigidity. Toget ultra-high precision operation and high precision machining.
3 axis boxway, a lower rapid feed speed but with more higher rigidity. That can reach a higher cutting output, since the boxway have a more widely contact surface it can bear heavey vibration buring operation.
